ISCAR TECH TALK - Introducing D42 Adapters and Blocks for the LOGIQ-F-GRIP Parting System
In the world of machining, innovation is key to staying ahead of the competition. That's why ISCAR is excited to introduce the D42 LOGIQ-F-GRIP adapters and blocks for parting bars with up to 42mm (1.65 inches). This new family of tool blocks is set to revolutionize parting applications and provide significant savings in raw materials.
One of the standout features of the LOGIQ-F-GRIP system is its unique patented captive adapters. These adapters are specially designed with a quad-shaped, patented 2 pocket design, ensuring a secure and reliable fit. This innovative design contributes to the outstanding stability of the parting system, even when dealing with large diameters. Machinists can now enjoy a vibration-free machining experience, resulting in improved insert tool life, superior surface finish, and enhanced workpiece straightness.
The LOGIQ-F-GRIP system also offers reduced cutting widths, thanks to its excellent tool stability. This stability not only enhances the machining process but also leads to material savings. In fact, it's now possible to cut a 42mm (1.65 inches) bar using just a 2mm (.08 inch) wide insert, maximizing efficiency and minimizing waste.
For those focused-on productivity, the LOGIQ-F-GRIP system guarantees high performance. When paired with TAG N-HF inserts, feeds of up to 0.35mm/rev (.0138 inch per revolution) can be achieved, ensuring fast and efficient machining operations. Additionally, setup time is significantly reduced after pocket replacement, as the adapters can be easily repositioned, saving valuable time on the shop floor.
Versatility is another key advantage of the LOGIQ-F-GRIP system. Two types of adapters, with widths of 2mm (0.8 inch) and 3mm (0.12 inch), fit seamlessly into the same tool block. This flexibility allows machinists to adapt to different parting requirements without the need for multiple tool blocks, streamlining operations and reducing costs.
To ensure optimal performance, the tool blocks are designed with a coolant-through hole directed to the cutting edge. This ensures effective chip evacuation and cooling during machining. While the adapters do not have cooling holes, the entire system is suitable for JETCUT coolant pressure of up to 140 Bar (2000 PSI), guaranteeing reliable and efficient operation.
Investing in the LOGIQ-F-GRIP system not only provides immediate benefits but also opens the door to acquiring additional parting applications. With its exceptional stability, tool life improvement, and material savings, machinists can confidently take on new projects and expand their capabilities.
In conclusion, the D42 LOGIQ-F-GRIP adapters and blocks are a game-changer in the world of parting applications. With their innovative design, outstanding stability, and enhanced productivity, they are set to redefine machining standards. Don't miss out on this opportunity to optimize your machining processes and unlock new possibilities. Experience the
LOGIQ-F-GRIP advantage today.
