Abstechen und Einstechen


Iscar tech talk - iscar's logiq-f-grip - extra stability & high productivity in parting & grooving

The revolutionary LOGIQ-F-GRIP parting system is designed to achieve extra stability and high productivity in parting and grooving operations. The LOGIQ-F-GRIP is a well engineered assembled tool block that comprises a unique durable holder and a highly stiff economical square type adapter with 2 and 4 insert pockets. ISCAR's parting systems are world renowned for their advanced geometries and high-performance cutting abilities. ISCAR's LOGIQ-F-GRIP tool block is intended for TANG-GRIP and DO-GRIP inserts in sizes of 2 to 5mm. ISCAR's LOGIQ-F-GRIP system is designed for parting bars in diameter sizes of up to 160mm. The new LOGIQ-F-GRIP line features: • Outstanding stability, vibration free parting system for large diameters as well. • Improved insert tool life, surface finish and workpiece straightness due to the robust tool design. • Reduced cutting widths as a result of excellent tool stability which leads to material savings. • Enables parting a 160mm bar with a 3mm insert • Economical Square Type blades with 2 and 4 insert pockets. • Guarantees high productivity, especially when using TAG N…HF (High Feed) inserts with feeds of up to 0.4mm/rev. • User friendly easy to use parting system. • Saves setup time after pocket replacement as the adapter can be repositioned easily. • Several types of square blades fit the same tool block. • Blades with or without coolant holes can be clamped on the same block. • LOGIQ-F-GRIP tools are suitable for JETCUT coolant pressure of up to 140 Bar. • Suitable for all machine types including Multi-Tasking machines which operate on a X axis with no need for additional adjustments. I would like to remind you to download the ISCAR World app which features the revolutionary NEO-ITA for achieving optimal machining results. https://www.iscar.com/ITA/home/machines #ISCAR, #LOGIQ-F-GRIP, #Parting&Grooving, #TANG-GRIP, #DO-GRIP, #JETCUT



ISCAR TECH TALK - Quick Change Tools for Machining Aluminum Wheels

ISCAR introduces a new range of Quick-Change Tools (DTF) with a dove tail connection for external and internal turning applications of aluminum wheels with the use of CUT-GRIP and ISO Turn heads. Based on the aluminum wheel industry demand for a quick-change tooling system, ISCAR introduces a new DTF quick change line. Features and Advantages of ISCAR's quick change tools: • The system provides a full solution for external and internal profiling, undercutting, facing, and boring operations. • The dovetail mechanism assures full-face contact between the shank and head with very high clamping forces, and can resist tough machining conditions, especially when machining aluminum wheels. • The unique system improves stability and rigidity during machining, and therefore, helps increase cutting parameters and tool life. • User-friendly with one screw provides very high clamping force. • Enables higher rigidity with a reinforced structure compared to integral boring bars. • Contains a variety of VDI40, VDI50 and round shanks. • The quick-change adaptation shortens the head replacement time and enables controlling the shank on the machine during head changes or when switching between jobs. • Guarantees high accuracy – repeatability within ±0.02mm. • The CUT-GRIP heads are designed for FSPA inserts that feature the many advantages of this insert line. • Designed for popular approach angles to support most wheel profiles. • Designed with coolant holes in the upper jaw to assure efficient chip control and longer tool life. I would like to remind you to download the ISCAR World app which features the revolutionary NEO-ITA for achieving optimal machining results. https://www.iscar.com/newarticles.aspx/countryid/1/newarticleid/2978 #ISCAR; #CUT-GRIP; #Boring; #MachiningAluminumWheels; #DOVETAIL; #RoundShanks; #ToolingSystem



ISCAR Industrealize - Aerospace - Blisk Titanium - Face Pocket - Rough Zigzag Turning

Face Pocket - Rough Zigzag Turning SUMO-GRIP Heavy Duty Line ISCAR’s unique groove-turn tools are multifunction turning tools, able to operate in a sequence of grooving and turning modes. The SUMO-GRIP line offers a very rigid and secure clamping in a tangentially oriented pocket. The extremely rigid clamping system, designed with the absence of an upper jaw, along with the strong insert design, enable the machining of groove-turn applications at very high feed rates, ensuring free and unobstructed chip flow. This results in improved insert and tool life and significantly increased productivity. Our SUMO-GRIP line also includes high pressure tools designed especially for machining hard to machine materials which are very common in the aerospace industry. The SUMO-GRIP inserts consist of different geometries allowing us to provide appropriate solutions for many groove-turn applications. In addition to our standard items, one of our unique specialties is providing full solutions for machining aerospace components. Our R&D department is highly experienced and has the ability to quickly design specially tailored items for the customer’s needs. for more information: https://www.iscar.com/newarticles.aspx/countryId/1/newarticleid/1658 https://www.iscar.com/newarticles.aspx/countryid/1/newarticleid/179 #ISCAR, #INDUSTREALIZE, #AerospaceIndustry, #TitaniumBlisk, #FacePockect, #SUMOGRIP
